Description
solar Air Conditioner Description
DC 48V Solar Power 100% Air Conditioner Series
In Sunshine Day, the Solar Panel Produce the Dc48v Power to Charge the Battery to Storge the Power,at the Same Time Provide the Power to DC48v Compressor and Fan Motor, then It Will Cooling or Heating the Room.the Indoor Motor, Compressor, Outdoor Motor in the New Generation 100% Solar Air Conditioner System All Adopt Brushless Dc Motor,it Greatly Improved the Stability and Efficiency of System.
| Model No | DQ3100A1HP-01 | DQ3100B1. 5HP-01 | DQ3100C2HP-01 | DQ3100D2. 5HP-01 | DQ3100E3HP-01 | ||||
| 1HP | 1.5HP | 2HP | 2.5HP | 3HP | |||||
| 0.75ton | 1ton | 1.5ton | 1.8ton | 2ton | |||||
| Capacity-Cooling | 9000 Btu/h | 12000 Btu/h | 18000 Btu/h | 20000 Btu/h | 24000 Btu/h | ||||
| Capacity-Heating | 10000 Btu/h | 13000 Btu/h | 20000 Btu/h | 24000 Btu/h | 27000 Btu/h | ||||
| Air Circulation | 450m³/h | 550m³/h | 550m³/h | 550m³/h | 550m³/h | ||||
| Suitable Area | 10~15m² | 12~25m² | 20~30m² | 26~42m² | 30~48m² | ||||
| Refrigerant | R-410A | ||||||||
| Work Temp. | -15~60℃ | ||||||||
| Power Input | 650W | 900W | 1300W | 1400W | 1500W | ||||
| Rated Current(A) | 28/14 | 35/18 | 27 | 30 | 33 | ||||
| Indoor Unit(MM) | 745*255*195 | 775*260*210 | 1070*385*265 | 1070*385*265 | 1070*385*265 | ||||
| Power Input(MM) | 645*245*495 | 790*260*540 | 1070*385*265 | 850*290*580 | 850*290*580 | ||||
| Indoor Unit(KG) | 11/13 | 13/15 | 15/17 | 16/18 | 20/22 | ||||
| Outdoor Unit(KG) | 38/40 | 45/48 | 48/52 | 48/53 | 48/55 | ||||
What Is Solar Air Conditioner：
Hybrid Solar Air Conditioner is Engineered from the Ground Up for Use with Solar. All Electrical Components Are Dc Powered Including Dc Compressor, High-efficiency Dc Fan Motors, Dc Valves & Solenoids, Etc. The Air Conditioner System Uses Vrf (variable Refrigerant Flow ) Controller and Frequency Driver in Conjunction with Multiple Sensors and an Algorithmic Control Circuit to Raise and Lower the Unit’s Capacity in Real-time Based on Conditions As They Change. Hybrid Solar Air Conditioner Uses Solar Direct Drive Technology(sdda), So the A/c Unit Can Use Ac Dc Power in the Same Time or Independently. the Solar Energy Will Be Used As the Priority Power Instead of the Grid Energy to Run the Air Conditioner. in the Sunshine Day, the Recreate Hybrid Solar Air Conditioner Can Be Operated by 100% Solar Energy Without Ac Power. The Whole System Just Contains an A/c Unit and a Few Pv Panels ( No Battery, No Inverter, No Controller). Compare with the Regular Air Conditioner, the Investment Increases 50%-80%, but the Electricity Bill Will Reduce 60-80% Yearly.
Details Images
Outdoor unit
Rust and corrosion resistance.
Compressor
Strong power, stable performance.
Motor
Pure copper coils increase efficiency.
Copper tube
Inner grooved design improve the heat transfer rate.
Double-muting technology
Keep the environment quiet and comfortable.
Strainer
Effectively prevents dust from entering, easy to remove and wash.
Production Line
